ARC-5 Radio Equipment from B-17 Bomber by Al Klase, N3FRQ

B-17 Aircraft ARC-5 Communication System

Al Klase, N3FRQ demonstrating his working B-17 Aircraft ARC-5 Communication System at the April 1997 meeting of the New Jersey Antique Radio Club. It was exciting to hear three dynamotors running, providing the high voltage to the three working receivers. Al is also an active member of "Boat Anchors", a computer network of collectors and appreciaters of TUBE radio equipment.

~ Click on any photo to see a full size picture. ~


Al Klase with WW-II B-17 Radio communications set-up. ~ Click on photo ~	Close-up of three Command ARC-5 Receivers ~ Click on photo ~


Inside Transmitter (left) and Receiver (right). ~Click on photo ~	Close-up of Antenna meter (left) and two Command ARC-5 Transmitters (right). ~ Click on photo ~

Photos by John Dilks, K2TQN
